Til
| Brend nomi | Blueway |
| Rang | Kulrang yoki oq |
| COP | 4,0 ~ 4,5 |
| Fan zaryadsizlanishi | Vertikal yoki gorizontal |
| Material | Galvanizli po'latdan yasalgan chang bilan qoplangan / plastmassa / zanglamaydigan po'lat |
| Maks/nominal harorat | 28℃/40℃ |
| Kelib chiqishi joyi | Guangdong Xitoy |
| Mahsulotlar turi | Hovuzdagi issiqlik pompasi |
| Sovutgich | R410A |
| Ilova | Uy, villa, SPA, maktab, mehmonxona, shifoxona |
| Mahsulot kalit so'zlari | suzish havzasi issiqlik pompasi, sovutgichli suv sovutgichi, sanoat suv sovutgichi |
| Model | SPCH-I-2.0S | SPCH-I-3.0S | SPCH-I-4.0S | SPCH-I-5.0S | SPCH-I-6.0S | SPCH-I-5S | SPCH-I-6S | SPCH-I-7S | SPCH-I-10S | SPCH-I-15S | SPCH-I-25T | |||
| HP | 2 | 3 | 4 | 5 | 6 | 5 | 6 | 7 | 10 | 15 | 25 | |||
| Quvvatlantirish manbai | V/Hz/Ph | 220-240/50/1, 208-230/60/1 | 380-415/50/3, 208-230/60/3, 380-415/60/3 | |||||||||||
| Isitish ko'rsatkichi | Isitish (1): A26/19°C W26/28°C |
Isitish quvvati | kVt/soat | 2,5~9 | 3,0~12 | 4,0~17 | 5,0~20 | 6,0~24 | 5,0~20 | 6,0~24 | 7~28 | 9~38,5 | 12~59 | 24~116 |
| Quvvat iste'moli | kVt | 0,2 ~ 1,65 | 0,24~2,22 | 0,33 ~ 3,2 | 0,42 ~ 4,15 | 0,51~5 | 0,42 ~ 4,1 | 0,5 ~ 4,95 | 0,58 ~ 5,5 | 0,75~8 | 1~12 | 2~23 | ||
| COP | w/w | 12,5 ~ 5,45 | 12,5 ~ 5,4 | 12.1~5.31 | 11,9 ~ 4,82 | 11,76 ~ 4,8 | 12~4,9 | 11,9 ~ 4,86 | 12,1~5,1 | 12~4,81 | 12~4,92 | 12~5.04 | ||
| Isitish (2): A15/12°C W26/28°C |
Isitish quvvati | kVt/soat | 1,8 ~ 7,5 | 2,2 ~ 9,5 | 3~12,5 | 4~15,5 | 5~20 | 4~15,5 | 5~20 | 6~23,5 | 8~31 | 10~48 | 20~93,5 | |
| Quvvat iste'moli | kVt | 0,27 ~ 1,7 | 0,33 ~ 2,1 | 0,48~3 | 0,66~4 | 0,81 ~ 4,94 | 0,65 ~ 3,92 | 0,81~5 | 0,95 ~ 5,75 | 1,31~7,9 | 1,65 ~ 12,5 | 3,4~24 | ||
| COP | w/w | 6,7 ~ 4,4 | 6,67 ~ 4,52 | 6,25~4,17 | 6,06~3,88 | 6.17 ~ 4.05 | 6,15~3,95 | 6,2~4 | 6,32~4,1 | 6,11~3,92 | 6.06 ~ 3.84 | 5,88~3,9 | ||
| Sovutish samaradorligi | Sovutish: A35/24°C W30/28°C |
Sovutish quvvati | kVt/soat | 2~5,5 | 3~7,5 | 5~10,5 | 7~12,5 | 7,5 ~ 14 | 7~12,5 | 7,5 ~ 14 | 8~17 | 15~25 | 18~38 | 36~72 |
| Quvvat iste'moli | kVt | 0,42 ~ 1,7 | 0,61 ~ 2,25 | 1~3,2 | 1,37 ~ 3,85 | 1,4~4,23 | 1,35~3,9 | 1,37~4,3 | 1,4~5 | 2,7 ~ 7,35 | 3,2~11,2 | 6,55 ~ 21,5 | ||
| EER | w/w | 4,76 ~ 3,24 | 4,92~3,33 | 5~3,28 | 5,1~3,25 | 5,36~3,31 | 5.19~3.2 | 5,47~3,25 | 5,7 ~ 3,4 | 5,56 ~ 3,5 | 5,63~3,39 | 5,5 ~ 3,35 | ||
| Atrof-muhit harorati. diapazon | °C | -7~46 | ||||||||||||
| Nominal/Maks. chiqish suv harorati. | °C | 28/40 | ||||||||||||
| Nominal suv oqimi tezligi | m³/soat | 3.8 | 5.2 | 7.3 | 8.6 | 10.3 | 8.6 | 10.3 | 12 | 16.6 | 25.4 | 50 | ||
| Nominal bosimning pasayishi | kPa | 4 | 5 | 5 | 7 | 13 | 7 | 13 | 15 | 15 | 17 | 23 | ||
| Nazoratchi | - | LCD displeyli mikro protsessorga asoslangan raqamli simli boshqaruvchi | ||||||||||||
| Tashqi shkaf | - | Chang qoplamali galvanizli po'lat | ||||||||||||
| Kompressor | Turi | - | Aylanadigan | aylantiring | ||||||||||
| Miqdor | No. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | ||
| Sovutgich | - | R32/R410a | ||||||||||||
| Suv issiqlik almashinuvchisi | - | PVX qobig'idagi titanium trubkasi | ||||||||||||
| Suvga ulanish | Kirish va chiqish | dyuym | DN40 | DN40 | DN40 | DN40 | DN50 | DN40 | DN50 | DN50 | DN65 | DN65 | DN80 | |
| Ovoz bosimi 1 m | dB(A) | 40~51 | 42~52 | 44~53 | 45~56 | 46~58 | 45~56 | 46~58 | 45~59 | 48~62 | 49~63 | 62~72 | ||
| Havoning chiqishi | - | Yon oqim | Yuqori oqim | |||||||||||
| Aniq o'lcham | W*D*H | mm | 950*380*610 | 950*380*610 | 1110*430*700 | 1100*430*800 | 1100*430*960 | 1100*430*800 | 1100*430*960 | 1050*400*1260 | 1100*480*1480 | 1400*525*1630 | 2000*950*2100 | |
| Sof og'irlik | kg | 43 | 45 | 54 | 70 | 90 | ||||||||
Sanoatga xos xususiyatlar
| Saqlash / Tanksiz | Saqlash |
| Turi | Issiqlik nasosli suv isitgichlari |
| Ilova | Tijorat, mehmonxona, maishiy, tashqi makon |
| Quvvat manbai | Elektr |
| Ilova tomonidan boshqariladigan | Ha |
Boshqa atributlar
| Voltaj (V) | 220 |
| Sotishdan keyingi xizmat ko'rsatiladi | Dala ta'mirlash va texnik xizmat ko'rsatish |
| Kafolat | 1 yil |
| Imkoniyat | 0 |
| O'rnatish | Mustaqil |
| Shaxsiy qolip | YO'Q |
| logotip/naqsh | Ipak ekranli bosib chiqarish, lazerli bosib chiqarish, issiq shtamplash, inkjet bosib chiqarish, UV bosib chiqarish, issiqlik o'tkazuvchan chop etish, 3D bosib chiqarish |
| Kelib chiqqan joyi | Guangdong, Xitoy |
| Brend nomi | Blueway |
| Model raqami | SPCH2.5S |
| Uy-joy materiali | Galvanizli po'latdan yasalgan chang bilan qoplangan |
| Brend nomi | Blueway |
| Rang | Kulrang yoki oq |
| COP | 4,0 ~ 4,5 |
| Fan zaryadsizlanishi | Vertikal yoki gorizontal |
| Material | Galvanizli po'latdan yasalgan chang bilan qoplangan / plastmassa / zanglamaydigan po'lat |
| Maks/nominal harorat | 28℃/40℃ |
| Kelib chiqishi joyi | Guangdong Xitoy |
| Mahsulotlar turi | Hovuzdagi issiqlik pompasi |
| Sovutgich | R410A |
| Ilova | Uy, villa, SPA, maktab, mehmonxona, shifoxona |
Qadoqlash va yetkazib berish
| Sotish birliklari: | Bitta element |
| Bitta paket hajmi: | 145X145X145 sm |
| Yagona yalpi og'irlik: | 68.000 kg |
